主要技術參數(shù)/Technical Data
| 名稱 |
appellation |
LMXMJ-1800 |
| 最大加工尺寸 |
Max processing size |
3100x1800x240mm |
| 設備外形尺寸 |
dimension of external form |
7000x2800x2180mm |
| 主鋸片最大直徑 |
The maximum diameter of main saw blade |
500mm |
|
分鋸片最大直徑 |
Saw blade diameter divided |
400mm |
| 主切電機功率 |
The main cutting motor power |
15-18.5kw |
| 分切電機功率 |
The cutting motor power |
11-15kw |
| 油壓系統(tǒng)電機功率 |
Hydraulic motor power system |
1.5kw |
| 臺車電機功率 |
Trolley motor powe |
1.5kw |
| 總重量 |
weight |
≈4500kg |
Remark: the processing dimensions (length and width), overall dimension of equipment and motor power are subject to customers’demands.
